The 2023 Big Tex 14TL-22BK is a heavy-duty, 22-foot bumper pull tilt-deck equipment trailer with a 14,000-pound GVWR, featuring a split deck design with 16 feet of tilt and 6 feet of stationary front deck, two 7,000-pound axles with electric brakes, a hydraulic dampening system for controlled tilting, and a 1/4" diamond plate rear knife edge.
Key Specifications
Manufacturer: Big Tex Trailers
Model: 14TL-22BK
Year: 2023
Hitch Type: Bumper Pull
GVWR: 14,000 lbs
Empty Weight: 3,660 lbs
Payload Capacity: 10,340 lbs
Overall Length: 22'
Deck Configuration: Split deck with a 16' tilt section and a 6' stationary front deck
Deck Width: 83" between fenders
Axles: (2) 7,000# drop-axles with forward-self-adjusting electric brakes and quick-lubricating hubs
Key Features
Tilt Operation: Hydraulic dampening system with a valve control for smooth, controlled loading and unloading
Deck Material: Treated Pine Floor (standard) or Blackwood Pro Rubber Infused Lumber Floor (optional)
