The RawMaxx MDX12BP10K is a 6x12 tandem axle dump trailer with a Gross Vehicle Weight Rating (GVWR) of 10,000 lbs. The "6x12" dimensions are a close approximation, as the actual dimensions are 12 feet long by 77 inches (6 feet 5 inches) wide. It features a hydraulic scissor lift and is primarily used for hauling and dumping heavy materials.
Key specifications
Dimensions: 12-foot length and 77-inch (6 feet 5 inches) width.
Capacity:
GVWR: 10,000 lbs.
Empty weight: Approximately 3,500 lbs.
Payload capacity: Approximately 6,500 lbs.
Axles: Two 5,200 lb electric brake spring axles from Dexter.
Frame and Construction: Built with a 5-inch channel frame and tongue, with a 10-gauge steel floor and 12-gauge 19-inch high sides.
Dump system: It uses a hydraulic scissor lift system with a 5x16 cylinder.
Doors and Ramps: Equipped with rear barn doors that may include integrated spreader doors, and 5-foot slide-out channel ramps for loading equipment.
Additional features:
Manual tarp kit.
Toolbox for the pump, battery, and charger.
Adjustable 2 5/16-inch coupler.
7,000 lb drop-leg jack.
LED lighting.
Spare tire mount (tire may not be included).
Common uses
The MDX12BP10K trailer is suited for a variety of tasks, including:
Hauling and dumping construction debris, gravel, and dirt
Transporting landscaping materials like mulch and topsoil
Moving equipment such as mini excavators and skid steers
